Cation Resin

In order to remove the calcium and magnesium from calcium-carbonate or magnesium-carbonate found in the water, we need to give the negative ions they are combined with, carbonate (CO3)-2, something else in exchange for the positive ions. By using an insoluble material, the ions may be pulled out of the solution and held in place.

The exchange process is about the ability of the resin bead to take on one ion while giving up another.

When the resin bead is fully loaded with sodium, it will readily give off sodium (Na+1) with one positive charge in exchange for calcium (Ca+2) with two positive charges.

When all of the exchange sites are loaded with calcium or magnesium, the resin beads are subjected to a high amount of salt (brine).

The high amount of salt in the brine forces the resin beads to give up the sodium and magnesium that are held at the exchange sites, and take on the sodium ions. The ions are exchanged. When the unit is rinsed, all of the removed calcium and magnesium, along with the excess salt that forced their removal, are washed down the drain. We are left with charged beads and no excess salt in the solution. The soft water contains no additional sodium as the unit is put back online.

It is with a strong acid-based exchange of styrene, and sulfonic acid polymer, the reaction of the special procedures results in a uniform size made of plastic-type particles. In dealing with the use of soft water, it has excellent, properties of strength and washing of the response properties of heat resistance, and the operation has a high capacity.

• Polymer matrix Structure: Polystyrene crosslinked with 7% DVB
• Functional Group: R-(SO₃)^–M⁺

Ionic Form, as shipped: Sodium (Na⁺)

Physical Form And Appearance: Clear Spherical Beads

Sphericity: 95% min
Screen Size Range — U.S. Standard Screen: 16-50 mesh, wet

Particle Size Range: 0.315-1.25mm

Uniformity Coefficient: 1.6 max.
Water Retention, Na⁺ Form: 45-50%
Swelling
Na⁺ > H⁺: 10% max.
Ca²⁺ > Na⁺: 5% max.

Packaging:

• • 25L / 20kg per packet.
